ESPECIFICACIONES:
Product Model
Product Model DS-D6055UT-D/S
Display
Screen Size 55 inch
Resolution 2160 × 3840
Active Display Area 1209.6 (H) × 680.4 (V) mm
Pixel Pitch 0.315 (H) mm × 0.315 (V) mm
Backlight E-LED
Viewing Angle 178°(H)/178°(V)
Contrast Ratio 1200:1
Brightness 500 cd/m²
Color Depth 10 bit (8 bit + FRC)
Response Time 8 ms
Color Gamut 72% NTSC
Reliability 7 × 24h
Refresh Rate 60 Hz
Haze 25%
Display Ratio 9:16
Panel Type IPS
Touch
Touch Type Capacitive Touch (G+G)
Touch Point 10
Touch Response Time < 25 ms
Touch Precision ± 2 mm
Built-in System
Operation System Android 13
Processor Cortex-A55, 4-core, main frequency 1.92 GHz
Memory 4 GB
Built-in Storage 32 GB EMMC
Interface
Video & Audio Input HDMI 2.0 (HDCP 2.2) × 1
Video & Audio Output Speaker (8Ω 5 W) × 2
Network Interface RJ45 × 1, Wi-Fi (2.4G/5G, 802.11 a/b/g/n/ac/ax) × 1, RS232 in × 1, RS232 out × 1
Data Transmission Interface USB 2.0 × 1, USB 3.0 × 1, BT 5.4 × 1
Power
Input Voltage 100 to 240 VAC, 50/60 Hz
Standby Consumption ≤ 0.5 W
Power Consumption 108 W (typ), 155 W (max)
Working Environment
Working Temperature 0 °C to 40 °C (32 °F to 104 °F)
Working Humidity 10% to 80% RH (Condensation)
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity 10% to 90% RH (Condensation)
General
Mounting Type Floor standing
Product Dimensions (W × H × D)
740 (W) mm × 1886 (H) mm × 480 (D) mm（With Stand）
727 (W) mm × 1776 (H) mm × 63.8 (D) mm（Without Stand）
Package Dimensions (W × H × D) 840 (W) mm × 1895 (H) mm × 155 (D) mm
Net Weight 46.5 kg
Gross Weight 52 kg
Packing List
Digital signage × 1, stand × 1, power cord × 1, user manual × 1, quick start guide × 1,
Regulation Compliance and Safety Information × 1, stand fixed with M8 screw × 6, key
× 2, foot pad ×4, energy efficiency label × 1, caster wheel × 4, wheel fixed with M4
screw × 16, Base fixed bracket × 2，Base fixed bracket with M4 screw × 4, Expansion
screw × 2
